Garaventa Home Lift HR

Customizable with a variety of colors, finishes, and materials to suit any style, budget or project. Compared to traditional manual accordion gates and swinging doors, Premium 3-speed Sliding Doors & Fixtures offer ultimate style, safety, convenience, and quality.

Garaventa Home lift HR
2021

Garaventa Home Lift HR

Garaventa Home Lift HR is Customizable with a variety of colors, finishes, and materials to suit any style, budget or project. Compared to traditional manual accordion gates and swinging doors, Premium 3-speed Sliding Doors & Fixtures offer ultimate style, safety, convenience, and quality.

All Garaventa Home Lift Elevator Control Systems are 100% tested in our factory. We make our own hydraulic cylinders! Each one is pressure tested to our exact standards. Uninterruptible Power Supply allows you to electronically lower the elevator cab in the event of a power outage.

Garaventa Home Lift HR isn’t just a functional addition to your home; it’s a chance to express your style. Home Lift HR is engineered to meet stringent safety standards while offering durability and long-term performance.

    • Available in 3 standard car sizes as well as custom sizes up to 18 square feet
    • Standard Car Sizes:
      • 36" x 48"
      • 36" x 54"
      • 36" x 60"
      • 40" x 50"
      • 40" x 54"
    • Available in 6 landing door configurations, including multiple door configurations.
    • Accordion car gate with safety switch in choice of black, white or antique white with or without 3 vision panels. Optional perforated aluminum, bronze acrylic or clear acrylic panels.
    • Wide choice of car wall panel colors and materials.
    • Choice of either brushed stainess steel or oil rubbed bronze finish on metal fixtures (handrail, operating panel, wall control plates).
    • Choice of either a quiet 1:2 Cable Hydraulic Drive or a machine room-less Geared Direct Drive.
    • Smooth start and stop.
    • Standard rated load of 750 lbs.
    • Nominal travel speed of 40 feet per minute. Travel range of up to 50 feet.
    • Make up to 6 stops or have a total of 6 landing doors.
    • Fully automatic push button operation.
    • Illuminated buttons and digital floor display.
    • Automatic car lighting upon passenger entry.
    • Recessed ceiling lighting using low-voltage L.E.D. fixtures.
    • Full length handrail located below the car operating panel.
    • Emergency backup power system for lights, locks and door operators.
    • Emergency stop and alarm.
    • Floor specific emergency battery lowering system.
    • Manual lowering capability.
    • Slack/broken cable safety brake device.
    • Hoistway door interlocks.
    • Solid car gate with safety switch.
    • UL or CSA certified components.
  • Rated Load Standard 750 lbs (340 kg) or 1,000 lbs (455 kg)
    Speed 40 ft/min (12.2 meters/min) nominal speed
    Travel Range Up to 50 feet (15.2 m)
    Stops Up to 6 stops
    Standard Controls Fully automatic push button operation | Digital floor indicator in car | Automatic car lighting upon entry |Illuminated push buttons
    Standard Safety Features Battery-powered emergency lowering | Safety brake system | Car door and hall door safety monitoring system | Emergency stop and alarm
    Hydraulic Drive System 1:2 cable hydraulic drive | Quiet submersed pump and motor | Two-speed valve for smooth start and stop
    In-Line Drive System Geared direct drive motor | Variable frequency drive for smooth start and stop | Speed monitor
    Power Requirements 230 VAC single phase | Optional 208 VAC 3 phase (Hydraulic Drive only)
    Popular Options Premium fixtures | Integral emergency telephone | 3-speed sliding doors
    Flooring By others to match the home decor | Minimum 1/8" thick | Maximum 3/4" thick
get BEST QUOTE

Get Quote

General FAQ

A stair lift is a motorized device designed to transport individuals up and down a staircase. It consists of a seat or platform that moves along a rail, allowing people with limited mobility to navigate stairs safely and independently.

Stair lifts are beneficial for individuals with mobility challenges, such as seniors, people with disabilities, or those recovering from surgeries or injuries. They provide a convenient solution for anyone who has difficulty climbing or descending stairs.

Yes, stair lifts are designed with safety as a top priority. They are equipped with features such as seat belts, safety sensors, and emergency stop buttons to ensure user safety. Additionally, professional installation and regular maintenance are essential for optimal safety and performance.

 Stair lifts can be installed as permanent fixtures, but they can also be temporarily installed or rented, depending on individual needs. Permanent installations provide long-term accessibility, while temporary options offer flexibility for shorter periods.
